Format uv led flatbed digital wood metal plexiglass printing machine in China
[VIPfirst7year] index:0
Deposit paid 0.00 $Deposit paid
Contact Seller
TEL:18080010997
Mobile Phone:
Email:viptxc@163.com
Mobile Phone:
Email:viptxc@163.com
Format uv led flatbed digital wood metal plexiglass printing machine in China
0 customer reviews
2 follows
Price:
$23000.00 - 25000.00 / Sets
Min.Order:
1 Sets
Contact Supplier
Chat Now! Request a custom order and have something just for you!
You may like
view more >
Quick Details
- Condition:
- New
- Place of Origin:
- Sichuan, China (Mainland)
- Brand Name:
- TXC
- Model Number:
- TXC2513E
- Dimensions(L*W*H):
- 4290*2150*1400mm
- Gross Power:
- 1200W
- Plate Type:
- Flatbed Printer
- Weight:
- 850kgs
- Automatic Grade:
- Automatic
- Color & Page:
- MULTICOLOR
- Certification:
- ISO/CE
- Usage:
- Bill Printer, Card Printer, Cloths Printer, Label Printer, Paper Printer, Tube Printer
- Voltage:
- 220V
- Product name:
- 3d printer
- Print head:
- Single or Double Ep DX5
- Ink type:
- Environmentally friendly UV ink
- Print size:
- Maximum 2500*1300mm(W*L)
- Print color:
- CMYK+4W/CMYKlmlc+2W/CMYK+2G+2W
- MOQ:
- 1 set
- Warranty:
- Two Years
- Printing resolution:
- 1440*2880dpi
- Payment terms:
- T/T(30% in advance and 70% balance)
- After-sales Service Provided:
- Engineers available to service machinery overseas
Supply Ability
- Supply Ability:
- 100 Set/Sets per Month
Packaging & Delivery
- Packaging Details
- Strong wooden package with full foam or as customer's requirement.
- Port
- Shanghai
- Lead Time :
- Shipped in 10 days after payment
Format uv led flatbed digital wood metal plexiglass printing machine in China
Product Description
Products Parameter
| Printer Parameter | |
| Model Number | TXC2513E |
| Print Head | Ep DX5, 2pcs |
| Print Size | 2500*1300mm |
| Medium Thickness | 100mm(customized) |
| Print Speed | 12m2/h |
| Print Direction | Bi/Uni direction |
| Print Color | CMYK+4W |
| Print Resolution | 2880X1440dpi |
| Plate Type | Flatbed |
| Printer head protection | Intellective automatic detect |
| Printer head maintain | Head clean during/after printing, keep-wet system when idle. |
| Materials to print | Metal, plstic, glass, wood, ceramics, acrylic, leather,etc. |
| Software language | Korean, German, French, Portuguese, Japanese, Spanish, Italian,Finnish,Dutch, English, etc. |
| System requirement | Windows XP/Vista/Win 7/Linus |
| Configuration Parameter | |
| Ink Dot Control | Variable-Size Droplet Technology |
| Ink Type | UV Curable Ink |
| Ink Color | Black, white, yellow, cyan, magenta |
| Ink Volume | 500ml |
| Ink supply system | Continuous Ink Supply System(CISS) |
| UV Lamp | LED UV lamps (Water cooling) |
| X, Y-Axis motors | Servo motors control |
| Software | RIP softwre |
| USB Interface | USB2.0; Ethernet |
| Power Requirement | AC220V 50Hz;AC110V 60Hz;1200W |
| Apperance parameter | |
| Dimension | 4290*2150*1400mm |
| Packaging Size | 4400*2360*1700mm |
| Packing | Strong wooden package with full foam. |
| Environmental Requirements | Temperature 10~35℃;Humidity 20~80% |
| Gross Weight | 950kg |
Product Characteristics
- Precision ball screw
- Fully mute imported precision guide rail
- LED cold light source UV curing lamp
- Nozzle collision avoidance system
- Imported servo motors
Product Show
Print Sample Shows
More Procucts
About Us
TXC technology established in 2011 is one of leading manufacturers for series UV flatbed printers. Its products have been exported to many countries and regions. Since establishment, TXC has been working on research and development of UV printers,Our products cover multifunction printer, UV printer, card printer, customized gift printer, T-shirt and garments printer and special printer. We also provide OEM services and accept customized order as well. Best quality and clients’ satisfaction is the goal we pursue.
Due to our plentiful manufacture and export experience, you are guaranteed to have competitive price, high quality products, on-time delivery and perfect after sales service, along with a smooth, trouble-free experience. We look forward to being your service.
